| Indoor unit: Cooling capacity | 24000Btu/h |
|---|---|
| Indoor unit: Sound pressure level (H) | 47 dB(A) |
| Indoor unit: Air flow | 1,250 m³/h |
| Indoor unit: Rated frequency | 50Hz |
| Indoor unit: Weight | 13,5 kg |
| Indoor unit: Rated voltage | 220 – 240 V |
| Climate type | T3 |
| Refrigerant type | R32 |
| Outdoor unit: Cooling capacity | 24000Btu/h |
| Outdoor unit: Refrigerant charge | 0,65Kg |
| Outdoor unit: Nominal cooling input | 3000W |
| Outdoor unit: Cooling power input | 2130W |
| Outdoor unit: Humidity protection | ɪPX4 |
| External unit: Sound pressure level | 56 db (A) |
| Outdoor unit: Excessive permissible operating pressure on suction side | 1,9MPa |
| Outdoor unit: Excessive operating pressure allowed for discharge side | 4,5MPa |
| External unit: Maximum allowable pressure | 4,5MPa |
| Outdoor unit: Insulation | ɪ |
| Outdoor unit: Weight | 43.5 kg |
| Outdoor unit: Rated voltage | 220-240 V |
|
BCC-24AAA-T3-INVERTER-R32Split Air Conditioners |
|
|
|      |
|
|
|
